• Yuri Caliper Gauges For Outside Measurement
1 1

Yuri

Yuri Caliper Gauges For Outside Measurement

Yuri Caliper Gauges For Outside Measurement

Specifications (Travel 10mm)
Order No. (Metric) Range Order No. (Inch) Range Accuracy
511-110 0–10mm 511-111 0–0.4" 0.02mm
511-120 10–20mm 511-121 0.4–0.8" 0.02mm
511-130 20–30mm 511-131 0.8–1.2" 0.02mm
511-140 30–40mm 511-141 1.2–1.6" 0.02mm
511-150 40–50mm 511-151 1.6–2.0" 0.02mm



Specifications (Travel 20mm)
Order No. (Metric) Range Order No. (Inch) Range Accuracy
511-210 0–20mm 511-211 0–0.8" 0.03mm
511-220 10–30mm 511-221 0.4–1.2" 0.03mm
511-230 20–40mm 511-231 0.8–1.6" 0.03mm
511-240 30–50mm 511-241 1.2–2.0" 0.03mm
511-250 40–60mm 511-251 1.6–2.4" 0.03mm



Features:

  • Suitable for measuring grooves and other hard-to-read outside dimensions
  • Resolution: 0.01mm (Metric); 0.0005" (Inch) for precise and accurate measurements
